Nominal Power (Pmax) : 240W
Open Circuit Voltage (VOC) 23,8V
Short Circuit Current (ISC) : 13,39A
Voltage at Nominal Power (Vmp) : 18,9V
Current at Nominal Power (Imp) : 12,69A
Module Efficiency (%) : 20,62
Cell type: Monocristalina 210x70mm
Number of cells: 36 (4×18)
Module dimensions: 1340x880x35mm (58.27×26.38×1.38inches)
Weight: 12kg (26.5lbs)
Front cover: 3.2mm (0.13inches) tempered glass with AR coating
Frame: Anodized aluminum alloy
Junction box: IP65, 2 diodes
Cable: 4mm2 (0.006inches2), 900mm (35.43inches)
Connector: MC4 or MC4 compatibleNominal Power (Pmax) : 240W
Open Circuit Voltage (VOC) 23,8V
Short Circuit Current (ISC) : 13,39A
Voltage at Nominal Power (Vmp) : 18,9V
Current at Nominal Power (Imp) : 12,69A
Module Efficiency (%) : 20,62
Cell type: Monocristalina 210x70mm
Number of cells: 36 (4×18)
Module dimensions: 1340x880x35mm (58.27×26.38×1.38inches)
Weight: 12kg (26.5lbs)
Front cover: 3.2mm (0.13inches) tempered glass with AR coating
Frame: Anodized aluminum alloy
Junction box: IP65, 2 diodes
Cable: 4mm2 (0.006inches2), 900mm (35.43inches)
Connector: MC4 or MC4 compatible
